AGS-8/2
Fire Extinguishing Aerosol Generator AGS-8/2
Designed for generating gas-aerosol mixture at concentrations required to extinguish a fire.
Recommended to use fire-extinguishing systems for premises of large volumes.
-
The generator consists of a cylinder with a metal case, which is located at the end of the nozzle cover. The AGS-8/2 is almost identical to the AGS-7/2,but due to labyrinth cooling system, the aerosol and air begins to mix, which significantly reduces the temperature of the gas-aerosol spray.Principle of operation:By applying an electrical or thermal pulse on node startup, a solid aerosol charge is ignited. Products of combustion pass through the nozzle on the cover of the generator, and the aerosol enters the designated area. Manufacturer’s warranty:
The manufacturer guarantees the generator to the technical requirements and Russian standards if the consumer follows the conditions specified in the instruction manual.
The warranty period for the generator – 18 months.
Exploitation period – 5 years.
Service period – 10 years.
-
Maximum protected volume conditionally sealed room
(d * <0,001 m-1)124m3 Curb weight of the generator 19.5 kg Weight of the aerosol charge 6.7 kg Working time 170 Dimensions Width 270 mm Length 352 mm Height 300 mm Activation starter BP-7.5-7.5 VRTH VEE, VELTH Resistance of the activation starter 7.5 ± 0.8 ohm 2.5 – 4 ohms Minimum start-up current 1А 0.4 А Starting voltage 12-24 1.5 – 24 The duration of the trigger pulse not less than 1.5 sec not less than 0.1 sec The inertia of the generator start <1.5 sec Operating Conditions Operating Temperature Range ± 50 °С. relative humidity at 25 ° C. 98% mechanical influences (in the frequency range up to 100 Hz) 0,5g Classes of fire-fighting
-
-
